Happy Joint

The revolutionary mini accessories with 3 entrances, pre-filled with gel and suitable for submersible installations (IPX8) complete with connectors

  • Extremely versatile - ready to use - re-enterable
  • Small, compact and robust
  • No need for tools
  • Pre-filled with gel, non toxic and no shelf life
  • Can energise immediately
  • For straight and branch connections
  • For rigid or flexible insulated wires up to 6 mm²
  • Up to 5 conductors on one phase or up to two conductors on two or three phases
  • Halogen free
  • UV resistant
  • Can be direct buried; perfect for garden lighting!
  • Fully submersible; great for marine applications such as bilge pump connections
Image of Happy Joint
Electrical performance:

CEI EN 50393:2006 as applicable

Gel:

UL 94-HB

Operating temperature:

90°

Installation temperature:

-40°C / +50°C

Degree of Protection:

IPX8

Be a PRO! Use filters.
Max No. x mm2
Combination
Dimensions L X W X H

HAPPYJOINT-3

4 Pack Size Clear
Max No. x mm2 3 x 1 - 4
Combination 2 through / 1 branch
Dimensions L X W X H 41 X 28 X 19
$24.00 ex. GST

HAPPYJOINT-4

2 Pack Size Clear
Max No. x mm2 4 x 1 - 4
Combination 2 through / in / out
Dimensions L X W X H 45 X 37 X 24
$16.00 ex. GST

HAPPYJOINT-5

2 Pack Size Clear
Max No. x mm2 5 x 1 - 4
Combination 2 through / 3 branch
Dimensions L X W X H 45 X 37 X 24
$16.00 ex. GST

HAPPYJOINT-6

1 Pack Size Clear
Max No. x mm2 6 x 1 - 4
Combination 3 through / in / out
Dimensions L X W X H 45 X 37 X 24
$9.00 ex. GST
