Description
Termco Blade Terminals – 2.5–6.0mm² Yellow
Blade terminals crimp onto a stripped conductor and present a flat blade end rather than a ring, fork, pin or bullet. Termco yellow blade terminals suit stranded conductors from 2.5mm² to 6.0mm², matching the yellow colour code.
Because the blade pushes straight into a matching socket contact, this range suits equipment sockets, fuse carriers and relay bases built to accept a blade end. Consequently, blade terminals cover a different mating style from a ring, fork or push-on terminal.
Blade Lengths, Types and Insulation
Specifically, this range covers blade lengths from 10mm to 17.5mm, in two blade types:
- Straight blade terminals
- Hooked blade terminals, with a small hook at the tip that helps resist pull-out in a press-fit socket
In addition, the range covers two insulation styles:
- Insulated — standard colour-coded insulated barrel
- Twin Grip Insulated — an alternative insulated design within the same range
A wider, heavier-duty Hooked blade terminal is also available in the Insulated style.
Applications
Installers use blade terminals for equipment sockets, fuse carriers and relay bases that accept a blade-ended terminal rather than a ring, fork or tab. Accordingly, this range covers the blade sizes commonly found in this equipment.
In all cases, correct crimping requires a ratchet crimping tool suited to insulated terminals in this conductor and colour range.
Termco Blade Terminals Australian Supply
Overall, Engineering Supplies stocks the full Termco insulated terminal range, including ring, fork, pin, push-on, blade and bullet terminals in the standard red, blue and yellow colour-coded sizes, throughout Australia.
Contact Engineering Supplies for pricing, availability or technical assistance on (08) 9258 8444 or email sales@engsup.com.au.
