Description
Phoenix Contact SZG 0,6X3,5 VDE screwdriver
The Phoenix Contact SZG 0,6X3,5 VDE is a stepped slotted screwdriver for test socket screws. Its blade is 0.6 mm thick and 3.5 mm wide, with a 100 mm blade length. The stepped tip is the key feature to check when choosing a tool for this type of screw.
The tool has a two-component Kraftform handle for a firm grip. In addition, its hexagonal handle shape helps stop it rolling across a bench when you put it down. The overall length is 198 mm, giving you a clear size reference for storage and access planning.
Dimensions and product details
- Manufacturer: Phoenix Contact
- Manufacturer part number: 1205121
- Engineering Supplies SKU: PC1205121
- Drive: slotted, with a stepped blade
- Intended use: test socket screws
- Blade thickness × width × length: 0.6 × 3.5 × 100 mm
- Overall length: 198 mm
- Tool width: 33 mm
- Blade material: alloyed tool steel
- Handle: two-component Kraftform with hexagonal roll stop
VDE testing and tool selection
Phoenix Contact lists VDE approval for this model and testing to IEC 60900:2004. The maker specifies use on or near live parts up to 1000 V AC or 1500 V DC. Use the tool within its stated limits and follow the electrical work procedures that apply to the task.
Before ordering, match the stepped blade to the test socket screw. Also check the space around the screw so that the blade and handle can reach it properly. A matching blade width alone does not establish fit for every terminal or screw head.
Further information and ordering help
See the Phoenix Contact SZG 0,6X3,5 VDE specifications, or browse our screwdrivers and terminal tools for other designs. For help selecting a tool, call Engineering Supplies on (08) 9258 8444 or email sales@engsup.com.au. Quote PC1205121 and provide the test socket or terminal part number.
